Laser cutting machine 3905 FiberStar T30
for metalfor ceramicssheet metal

Laser cutting machine - 3905 FiberStar T30 - Laserstar Technologies Corporation - for metal / for ceramics / sheet metal
Laser cutting machine - 3905 FiberStar T30 - Laserstar Technologies Corporation - for metal / for ceramics / sheet metal
Add to favorites
Compare this product


Characteristics

Technology
laser
Material
for metal, for ceramics
Product handled
sheet metal, for plastic pipes
Control type
with programming software
Associated function
for welding
Applications
for the automotive industry, for the electronics industry, for medical applications, for jewelry
Phase
single-phase
Configuration
4-axis
Other characteristics
programmable, rotary
X travel

12 in

Y travel

12 in

Z travel

6 in

Cutting speed

2,050 mm/s

Laser power

150 W, 300 W, 600 W

Repeatability

0.01 mm
(0.0004 in)

Acceleration

3 m/s²
(10 ft/s²)

Overall length

737 mm
(29 in)

Overall width

699 mm
(28 in)

Height

1,912 mm
(75 in)

Weight

700 kg
(1,543.24 lb)

Description

The FiberStar Tower Laser Machining Centers offer a significant competitive advantage for today’s marketplace while producing high quality, dimensionally accurate results. The state-of-the-art, fully integrated laser source provides excellent beam quality while producing many years of reliable performance. The FiberStar Tower Laser Worksations offer a programmable 4-Axis (X/Y/Z and optional Rotary) CNC system controller, integrated computer with Windows operating system, and comes ready to use with LaserStar machining software and DXF-GCODE Conversion Software. This system is air cooled. As a turnkey solution provider, LaserStar’s Applications Specialists will evaluate your welding or cutting requirements, define the application goals and objectives, specify and verify the correct technology, and define a complete system configuration to accomplish the desired results. •Medical Device and Instruments •Tool & Die Components •Aerospace and Electronics •Prototyping Components •Automotive and Micro Components •Complex Industrial Alloys •Jewelry (Gold, Silver, Platinum, Titanium) •Ceramics and Plastics
