O-ring seal LATTYflon 97roundstainless steelPTFE
Add to favorites
Compare this product
Characteristics
- Type
- O-ring
- Configuration
- round
- Material
- stainless steel, PTFE
- Application
- for chemical applications, for food industry machinery
- Other characteristics
- chemical-resistant, molded
- Temperature limit
Min.: -100 °C
(-148 °F)Max.: 250 °C
(482 °F)- Pressure limit
Min.: 0 bar
(0 psi)Max.: 100 bar
(1,450.4 psi)
Description
PTFE SHEET : CHEMICAL RESISTANCE FOR STATIC SEAL APPLICATIONS
Moulded PTFE gasket over an ISO 1.4306 perforated stainless steel insert. LATTYflon 97 offers an outstanding resistance to cold creep due to the specific design of the perforated plate reinforcement. LATTYflon 97 is very moisture resistant and can be stored for unlimited time. Limitation: not to be used on fluorine-containing gases or molten alkali metals. 100% PTFE gasket with metal insert for improved mechanical strength.
Fluids : For all fluids, Compatible with all fluids except strong oxidants
Material : Pipes flanges
Parameters
pH : 0 - 14
Type of industries
All chemical industries, machine engineering, food-processing industry.
