Pad printing machine with closed ink cup AP-260100
automatic2-colorfor the toy industry

Pad printing machine with closed ink cup - AP-260100 - LC Printing Machine Factory Limited - automatic / 2-color / for the toy industry
Pad printing machine with closed ink cup - AP-260100 - LC Printing Machine Factory Limited - automatic / 2-color / for the toy industry
Add to favorites
Compare this product


Characteristics

Type
with closed ink cup
Control
automatic
Number of colors
2-color
Domain
for the toy industry, for the electronics industry, for the pharmaceutical industry, for the cosmetics industry, for the beverage industry, automatic, for caps, for balls, electrical switch
Other characteristics
electropneumatic, rotary, high-speed, pneumatic
Printing speed

Min.: 1 p/min

Max.: 80 p/min

Description

Product name:Softball Ink Cup Pad Printing Machine Model Number: AP-260100 Softball Ink Cup Pad Printer Description Standard Steel Plate Size:260*100mm Ink Cup Diameter:Φ90mm Max. Printing Diameter: Φ80mm Max. Pad Downward Stroke: 80mm Max. Pad Carriage Stroke: 248mm Printing Pad Rotation: degree 360° Worktable Adjustable Angle: degree 5° Printing Pad Pressure (6bar hr): N 2954 Compressed Air Pressure: bar 5-7 Compressed Air Consumption: L/cycle 2.38 Power Supply: Single Phase:AC 220V±10% Power Consumption: W 60 Noise Level: dB ≦76 Machine Dimension: L*W*H 99*83*165cm Machine weight: 220 KG Normal Air Consumption is defined as transferring 6 bar of compressed air into normal condition at sea level and 20 degree Celsius under normal atmospheric pressure. Please specify at order when machine requires to work under 110V supply.
