Video measuring system SPC500

coordinatedimensionalautomatic

Semi-automatic Video measuring System Usage： SPC series two-element measuring instrument is suitable for all application fields with the purpose of two-dimensional coordinate measurement. It is widely used in precision machinery, electronics, instrumentation, plastics, mobile phone tablet, hardware mold, PCB, LCD, LED display and other industries. Features： ■ High-precision marble base, table and column to ensure high stability and rigidity ■ Marble table design, with precision V-shaped cross rail, ensure long-term use without deform, effectively guarantee high mechanical precision ■ Z-axis with Panasonic servo motor for auto-focus ■ High-quality optical system and high-resolution CCD ensure sharp image edges ■ Three-ring and eight-zone LED ring surface cold light source and contour light source, avoid the deformation of precision parts caused by the heat from light ■ Optional fully automatic zoom lens, no need re-calibrate when changing magnification, save calibration time and avoid human error ■ Optional Renishaw contact probe for height, depth and other 3D measurement ■ Independent research and development of image measuring software, powerful and easy to operate
