- Constant-torque hinge
- LEECO Technologies Corporation
Constant-torque hinge CD20Bsteelscrew-innickel-plated
Add to favorites
Compare this product
Characteristics
- Type
- constant-torque
- Material
- steel
- Installation
- screw-in
- Finish
- nickel-plated
- Opening angle
- 360°
- Applications
- door, for panels
- Length
32.1 mm
(1.264 in)- Width
32.1 mm
(1.264 in)- Thickness
23.7 mm
(0.933 in)- Torque
Min.: 2.5 Nm
(1.84 ft.lb)Max.: 5 Nm
(3.69 ft.lb)
Description
Applications:
Display panels, hinged doors, industrial enclosures, office equipment, housing appliance, medical equipment, seating…
Torque ratings: 2.5, 3.0, 4.0 and 5.0Nm Symmetric
Cycle life: Over 10,000 cycle life within ±25% of static torque specification
Materials: Steel and grease
90 or 360 degree shaft rotation
Plating finish
M3 screw mounting hole
Zero backlash
Minimal or no springback
RoHS and REACH compliant
