Laser line sensor LPS 36

digital

Contains - LxSsoft configuration software Application - Contour measurement Object measurement Laser class - 2M, IEC/EN 60825-1:2007 Resolution of x-axis - 1 ... 1.5 mm Resolution of z-axis - 1 ... 3 mm Repeatability of Z-axis, relative to measurement distance - Repeatability of Z-axis, relative to measurement distance, note - Reflectivity 90 %, identical object, identical environment conditions, measurement object ≤ 50x50 mm² Measurement time - 10ms Linearity of Z-axis, relative to measurement distance - ± 1,0% Black/white behavior - 1 %, 6 … 90% diffuse reflectance Supply voltage UB - 18 ... 30 V, DC Number of activation inputs - 1 Piece(s) Number of digital switching inputs - 2 Piece(s) Number of digital switching outputs - 2 Piece(s) Switching element - Transistor, Push-pull Function - Switching element - Transistor, Push-pull Function - Type - Ethernet Number of connections - 2 Piece(s) Function - Signal IN Signal OUT Voltage supply Type of connection - Connector Thread size - M12 Type - Male Material - Metal No. of pins - 8 -pin Encoding - A-coded Function - Configuration interface Data interface Type of connection - Connector Thread size - M12 Type - Female Material - Metal No. of pins - 4 -pin Encoding - D-coded Dimension (W x H x L) - 56 mm x 160 mm x 74 mm Plastic Metal housing - Aluminum Lens cover material - Glass Net weight - 620 g Ambient temperature, operation - -30 ... 50 °C Ambient temperature, storage - °C Protection class - III, VDE Certifications - c UL US Standards applied - IEC 60947-5-2
