X-ray diffractometer YX-8D

single crystal

Usage: Special designed for 8 inch and super long and over weight Silicon ingot and single crystal Square brick, this unit had the advantage of steady structure, simple operation. It is the inspect unit for over size and over weight Silicon crystal manufacture and process. NoItemParameter 1Power inputSingle phase 220V、50Hz 、capacity 0.5KW 2X Ray tubeCu Bar, Anode grounding, air cooling 3Tube Voltage30 KVP、full voltage closed shutter 4Tube Current0--5mA、continuous adjustment 5Comprehensive accuracy±30″ 6Operation methodManual 7Angle adjustmentDigital display can be set at any angle 8Peak value displayX Ray intensity table（µA table） 9Digital DisplayDigital tube display angle 10Counter tubeGeiger counter tube, voltageDC700—1200V 11Crystal size（round ingot、Square brick）Largest diameter is during 160mm to 220mm Length not larger than 800mm 12Material FeedingAuto automatic feeding, shutter controls feeding position, accuracy 0.03mm 13ProtectionHigh Voltage chain, temperature protection 14Unit out drawing dimension1200（length）×1100（width）×1200（height）mm 15Control cabinet size590（length）×400（width）×1180（height）mm
