Aluminum grating BN-O

steelstainless steelgalvanised steel

With perforated metal planks, type BN-O “Noppe, offen“ the bothsided punched holes have a diameter 8 mm and allows an excellent standing stability. Furthermore the drain holes exhibit good drainage. The BN-O grating guarantees a high stability for normal pedestrian traffic. Material - Steel S235JR: 2,0 mm, 2,5 mm Stainless steel: 1,5 mm, 2,0 mm Aluminium: 2,0 mm, 2,5 mm Surface treatment - Steel: untreated, hot-dip galvanized, pre-galvanized Stainless Steel: untreated, pickled Aluminium: untreated, pickled, anodized Free cross section - max.~ 5,0% Width - 150 mm, 200 mm, 250 mm, 300 mm (other widths on request) Height - 30 mm, 50 mm, 75 mm, 100 mm, 150 mm (Corresponding to width and statical specification; other heights on request) Ball proof - Ø 10 mm (a Ø 10 mm ball don´t fall through / 10 mm ball proof) Serration - R11 / V10 (Steel, hot-dip galvanized IFA 1504066) Longitudinal grid - 125 mm (62,5 mm) Production length - max. 10 m, depending on transport limit
