Control foot switch 571-DWN

electricRF wirelesssingle pedal

Rugged cast metal enclosure has sufficient weight to keep the switch from sliding when being operated All models have a neoprene cover gasket plus O-rings on the activating shaft and a separate ground screw In all Maintained Contact models the release is accomplished by simply pressing the latch with a light forward movement of the toe. The release is placed under the Full Shield so falling objects cannot easily release it 3 holes provided for rigid mounting to the floor or equipment Materials Treadle, cover and housing constructed from cast iron for strength and durability Painted Alert Orange Single 3/4"-14 N.P.T. threaded conduit entry is standard Options Oversize "O" and "OX" Shield models accept oversized safety shoes and metatarsal foot guards. The "OX" Shield has an additional 3/4" (19.1 mm) opening height as compared to the "O" shield Dual 1/2"-14 N.P.T. threaded conduit entry and metric sizes available to the O.E.M. on special order Special Twin & Triple Models available to the O.E.M. on special order Potentiometer models are available RF Wireless models are available Hercules models available with cast aluminum base and covers (except unshielded cover which is gray iron) Applications Benders Box Marker Brakes Chopper
