16-key keypad LP3672

panel-mountmetalstainless

1. Metal Keyboard with LED backlight 2. Twenty five custom made keys 3. Based on Modbus over RS 485 communication protocol 4. Configured as slave 5. Slave ID selection up to 255 6. Baud rate configurable (default:19200bps) 7. Over voltage and short circuit protection 8. Key pressed indication using buzzer 9. Input voltage 24v dc, current capability up to 5A 10. Key activation force 200 to 350 gms depending on the switching element 11. Key switch lifespan: more than 10 million of operations 12. Dimensions: 114mm x 187.5mm 13. Key switch technology: metal dome and rugged PCB 14. Mounting style: Rack mount or top mount 15. Laser engraved characters for excellent durability 16. Metal Plate material : stainless steel Function: RS 485 communication with configurable baud rate guided by Modbus protocol Applications: 1. Point of Sales 2. Process control panel
