Nominal Capacity @ Radius
75 USt @ 9 ft
Standard Boom
41 - 127 ft
Telescope System
Latching
Attachment - Option 1
A: 38 ft Lattice / B: 38 - 64 ft Lattice
Attachment - Option 2
A: (1) 16 ft insert / B: (2) 16 ft inserts
Maximum Tip Height
230 ft
Maximum Line Pull
16,880 lbs
Maximum Speed
460 fpm
•Greaseless 41ft – 127 ft pin & latch four-section boom
•Manually offsettable one or two piece fly: offsettable to 2°, 15°, 30°, and 45°
•Full fly is stowable on the machine: no capacity deducts for stowed attachment
•Excellent transportability – can be configured to meet some of the toughest transportation laws in North America
•Transports under 95,000 lbs with 14,400 lbs of counterweight, fly, and 10t ball installed
•“Stow ‘n go” outrigger pontoons are easily secured for transport
•Cummins X12: EPA 2022 Compliant On-Highway 450 HP engine
•ZF AS-Tronic (no clutch pedal) Manual Transmission
•Link-Belt Pulse operating system including CALC selectable outrigger extension system
•Link-Belt Vision Package: Standard
•Flat Deck design- maintains four points of access regardless of upper position
•Pull-out CabWalk for ease of access to and from the operator’s cab
