Chamber furnace SA

sinteringdryingcuring

curing, firing For curing of onglaze colours on porcelain and glass. Other possible applications are: The most important characterstics The transport is done via a flat wire link belt of the material 1.4828. Frequency-controlled transport speed in a range of 0,08 – 0,3 m/ min. The heating system of FeCrAl heating elements in the cover and in the bottom is divided crosswise to the transport direction into 7 control zones with each 36 kW. Heat recirculation out of the cooling zone via a low pressure high performance ventilator with a volume flow of 9300 m³/ h in the area of the inlet zone/ pre-heating zone. Staggered exhaust system with manually operated throttle valves in the area of the first two zones. Easy operation and handling Robust design Flexible applications Quality made in Germany Options Different further temperature program controller Screen recorder Process guiding software depending on control system
