Tire materials handling clamp LTJ D-B/C

Designed for tyres handling and stacking operations and applied widely in tyre manufactures, ware-house and logistic transportation companies. It can handle either horizontally locating tyre or vertical ones, and can rotate with 360°. With features of lower operator’s intensity, lower running costs, safety and high production efficiency. - - Capacity: 1200Kg – 2000Kg - - Type Diameter: 350mm – 1800mm - - Mounting Class: II/III - - Long Arm Length: 820mm – 1175mm - - Short Arm Length: 550mmm – 795mm - - .Long Arm Thickness: 85mm/95mm - - Contact Pad Size: 230*1500mm/300*1500mm - - Vertical Center of Gravity: 280mm/243mm - - Weight: 460KG – 986KG - - Effective Thickness: 150mm/256mm - - Horizontal Center of Gravity: 250mm/345mm Recommend Hydraulic Flow: 40L/min –120L/min Pressure: 160 Bar Rotating Speed: 7.5r/min@40L/min 5.2r/min@40L/min Rotating Torgue: 4200Nm@160Bar 9000Nm@160Bar Note: 1. Please contact FLT manufacture for the residual capacity of attachment 2. 2 additional hydraulic circuit required 3. Type “A” fixed short arms, Type “B” adjustable short arms, * Further technical details are available upon request
