Diaphragm pump 0205-505electricsubmersiblemobile
Add to favorites
Compare this product
Characteristics
- Technology
- diaphragm
- Operation
- electric
- Priming
- submersible
- Mobility
- mobile
- Domain
- industrial, for the petrochemical industry, for the automotive industry, for the printing industry
- Applications
- transfer, drum, drain
- Material
- stainless steel
- Fluid specification
- for flammable fluids, for hazardous fluids
- Protection level
- explosion-proof
- Flow
Min.: 0 l/min
(0 us gal/min)Max.: 77 l/min
(20.34125 us gal/min)- Head
Min.: 0 m
(0'00" )Max.: 14 m
(45'11" )- Power
460 W
(0.63 hp)- Fluid temperature
100 °C
(212 °F)- Input diameter
41 mm
(1.614 in)
Description
Drum pump for complete drum drainage - solvents
The Pump Set is suitable for thin, flammable and inflammable liquids and hydrocarbons. Perfectly suited for withdrawing or transferring explosive media and solvents.
* Optionally available with Ex - plug
* Pump tube equipped with Lutz original hand wheel
* Suitable for Drum emptying alternative fuels, oils, flammable liquids
Features & Advantages
* Optionally with electric or compressed air drive
* No lubricants and therefore no contamination of the pumped medium by lubricants
* Optimised Drum emptying with a remaining quantity of approx. 0.1 litres
* No leakage if the pumping station is tilted or moved
* Maximum product utilization with reduced drum cleaning and disposal rates
* Approved according to ATEX directive 2014/34/EU, category 1/2
Catalogs
Lutz Drum and Container Pumps
100 Pages
