Wear-resistant steel grader blade GR 220/270

The grader “dual” M3 is an equipment with double function: it works both as a grader blade and as a tilt dozer blade, with the wheels raised. With a blade width of 2200 mm, it can reach 2700 mm thanks to the extensions bolted on supplied as standard. Its structure highly compact allows you an excellent visibility from the cab and accessibility to the skid loader. The floating front wheels ensure a high adaptability to the ground. The blade is bolted and in steel Hardox 450 HBW. If compared to competitors, it proves to be higher and thicker, facilitating a greater moving of the material. The blade has countless angling possibilities. The Grader Blade M3 Model Dual can be fitted to small skid steer loaders with power ranging from 50 to 120 HP. IT is ideal for the preparation and the leveling of lands, roads and yards. It is equipped with a hydraulic control panel of the 26° inclination system, of the oscillation at 15°, of the blade height adjustment ± 150mm, of the lifting of the front wheels, a distributor on / off, blade extensions, coupling to the machine, hydraulic hoses and electric control kit. - Width blade mm 2200 or mm 2700 thanks to the bolted extensions supplied as standard. - Front axle floating wheels: high adaptability to the ground. - First quality steel, bolt-on blade in wear-resistant steel 450 HB - One-piece hydraulic system fully protected into the frame, hydraulic hoses with with sleeve and cylinders with block valves. - Neumatic tyres. - Grader Control device : control box, high-sensitivity electrohydraulic controls, hyone-piece hydraulic system with two proportional elements and two on / off elements.
