Features
Super brightness led platform light.Use OSRAM LED Chip and Meanwell Driver;
Excellent anti-explosion,anti-corrosion and durability,safe use in all kinds of inflammable and explosive hazardous area,such as petrochemical plant,powder plant,gas equipments;
Aluminum Integratied lamp housing make chip connect with housing tightly,through cooling fins and special airflow structure,make excellent heat radiation;
Almost free maintenance required,IP66 water proof and dust proof,100000 hours lifespan;
Intelligent power regulator supplement luminous flux and reduce luminous decay,with protection of overvoltage,over current,and surge current;
Gas explosive environment:Group IIA,IIB,IIC;
For Gas Zone 1,Zone2;For Dust Zone 21,Zone 22;Temperature class: T1 to T6;
Model
MAXL-5050F
MAXL-5070F
Light Type
Platform Light
Voltage
AC100-240V / DC24V / DC36V
Protection Class
Exd II CT6 Gb,IP66
Insulation Degree:I,
Corrsion Resistant:WF2,
Rated Power
50W
70W
Equivalent
MH Lamp
150W
175W
Luminous Efficacy
Up to 130 Lm/W
Luminous Flux
6500Lm
9100Lm
Mounting Height
6-8m
Lens Angle
60°
90°
110°
Space Height Ratio
0.9
1.35
1.4
CRI(RA)
>70
CCT
5000K
Power Factor
>0.9
Life Span
100000 Hours
Leading Cable Diameter
D8-14mm
Cable Inlets
Screw Thread
M20×1.5,M25×1.5,NPT1/2",NPT3/4",G3/4"
Material
Lampshade:Explosion Proof Tempered Glass;
Housing:DIECAST Al;
Operation Temp
-45 – 70℃
Weight
5.5Kg
Install Way
Bracket / Ceiling / Wall Mounted / Pole / Flange
Measurement
D245*320mm
