TFT LCD display module MLD091-12832A
OLEDmonochromegraphic

TFT LCD display module
TFT LCD display module
Add to favorites
Compare this product


Characteristics

Screen type
TFT LCD, OLED
Type
monochrome, graphic
Format
128 x 32
Screen size
0.91"
Applications
industrial, for medical equipment
Interface
SPI
Configuration/mounting
portable, outdoor
Other characteristics
wide-viewing angle, smart
Width

30 mm
(1.1811 in)

Height

11.5 mm
(0.4528 in)

Description

The 0.91 inch oled module, is a graphic passive matrix oled display, with FPC connection, it is a COG structure OLED display, it have 128x32 dots, white on black, wide viewing angle, wide temperature, high brightness, high contrast, fast response time. OLED display module characters-0.91 inch oled: because it is OLED display module, oled could be emitting light by itself, no need for backlight, so oled display module would be thinner than tft lcd module, and it don't like tft lcd, oled display have no viewing angle limited, OLED display is wide/full viewing angle, oled display have excellent display performance in all viewing angle. 0.91’’ OLED lcd display module could be displayed in wide temperature, its working temperature could be reached to -40 degree, and 80 degree. 0.91’’ 128x32 OLED screen is the best display solution in the outdoor display, such as sunlight environment, and also for industrial or medical application that need the wide viewing angle and high brightness display. And it’s often used for smart watch, MP3, function cellphone, portable health device and many others application
