Display Type - 7" LCD
Resolution - 1280 x 800 pixel
Touch Type - PCAP (10 points)
CPU - Intel® Atom™ x5-Z8550 Processor (Cherry Trail Type 4)
Memory - LPDDR3 1600MHz, 4GB
Storage - Single eMMC 4.5, 64GB
Operating System - Windows 10 64bit (optional)
Communications - Wi-Fi 802.11 a/b/g/n/ac
Bluetooth v4.0
GPS & GLONASS
NFC: NXP NPC100 , ISO14443 Type A, Type B,
PC/SC (windows driver support )
3G/LTE (optional module)
Sensor - E-compass, G-sensor, Gyro, Ambient Light sensor
IO Ports - 1 x Docking Port (with AC-IN, HDMI, USB)
1 x Micro SD card slot
1 x Mic/Head phone jack combo
1 x micro USB port (OTG)=>USB3.0 micro Type B
Camera - Front Camera : 2.0M
Rear Camera : 8.0M
Control Buttons - Power, Volume Up ,Volume Down
Battery - Li-polymer 4100 mAh/ 15.17Wh
Ingress Protection - IP54
Speaker - 2x Speakers, 1W x 8 Ohm
MIC - 1x DMIC
Operating Temperature - 0°C ~ 40°C
Operating Humidity (RH) - 10% - 95% non-condensing
Storage Temperature - -20°C ~ 60°C
Storage Humidity (RH) - 5% - 95%
Vibration - 4Gs Peak, 5Hz to 2kHz, 1 Hour Duration per axis
Drop Test - 0.8m / 2.7ft. Drop to steel Surface, 1 drop per 6 sides
Dimensions - 200mm x 125mm x 23.5mm
Weight - 490g
Certifications - FCC Part 15 Class B, CE, IEC60601
Optional Devices - 1D/2D Barcode Scanner, 3G / LTE Module, Smart Card Reader (contact), MSR, Ethernet Giga LAN RJ45 Port
Docking - Optional
