Roller crusher FRT series

stationary

Even if they have long been used in dry bottom ash applications, the Magaldi Single-Roll crushers are suitable to operate under severe conditions to handle the broadest possible range of materials (waste heat boiler slag, big lumps, and bottom ash), effectively reducing the material size and providing high efficiency, reliability, and uptime while considerably lowering the percentage of fines. Magaldi has developed many tailored solutions. The product family consists of models of different sizes (27’’, 54’’, 67’’, 81’’) depending on the required final particle size and capacity. Magaldi Single-Roll Crusher features a toothed roll assembly, which crushes the incoming feed material against anvil plates. When the material enters through the inlet chute, the teeth of the rotating cam shear and split the chunks against the anvil plates. The crushed material is cleared and dropped down, through the crusher outlet chute, into a collecting bin or conveying equipment. The clearance between the roll and the anvil plates can be adjusted to set the maximum particle size at the crusher outlet. The core of Magaldi Crusher is a single-roll cam, whose design produces more crushing force than a double-roll design while reducing initial cost and power consumption.
