MagicRAM 2.5″ SATA III SSD is a rugged SSD and extremely reliable storage solution in harsh environments with capacity up to 2TB and extreme SATA III performance up to 510/480 MB/Sec (Max).
MagicRAM 2.5″ SATA III SSD is designed with SLC, pSLC, MLC or TLC NAND Flash and is available with an optional -40C to +85C extended temperature range version.
Form Factor2.5″ SATA III
Flash TypeSLC, pSLC, MLC, TLC
Density1GB to 2TB
PerformanceSequential Read speed up to 510MB/s | Sequential Write speed up to 430MB/s
Random Read (IOPS) up to 70K | Random Write (IOPS) up to 64K
Transfer ModeSATA 1.5Gbps/3Gbps/6Gbps
Operating
TemperatureCommercial Temp: 0°C to 70°C
Industrial Temp: -40°C to +85°C
Shock & VibrationShock: 1500G@0.5ms
Vibration: 20G@80Hz~2000Hz
