Screw conveyor belt fastener U30

staplefor mining equipmentfor industrial applications

The High Perfomance System is extremly effectife when installed in high strength belts where safety and reliability is essential. The main applications are: Coal Mining, Ore Mining, Gravel Pits and Quarries, Cement Plants, Snowcats, Industry ​ Plate material: • Stainless Chromium Steel Staple material: • Spring Steel • Optimised for best static pullout strength and dynamic life time. Fastener: • Dispatched in boxes with Fastener Strips of 200mm length, (can be shortened individually). • Content is sufficient for one complete lace of according belt width (without Connecting Pin) for standard width of 1.000, 1.200, and 1.400 mm. Connecting Pins: • High Tensile Stainless Chromium-Nickel Cable with special steel wrapping e.g. for long life time P1S, for extreme wear resistance P1C or P1K. Sealed Version U30+ Fastener material identic to U30 • Additional sealing, prevents spillage of material. • Significant increas of Connecing Pin life time, by grease filling in sealed loop areas. For easy installation MATO recommend to use screw Connecting Pins ("G") e.g. for long life time P1SG, for extreme wear ressistance P1CG or P1KG.
