Rogowski coil current sensor RCT-600T

ACmonitoring

RCT-600T Rogowski Coil Measures AC current up to 5,000 Amps. The RCT-600T Flexible Rogowski Coil opens at the connector junction and can be installed on an existing cable or buss-bar in a matter of seconds. This “tear-drop” style design facilitates installations with limited electrical panel space. In addition, because of its design, positioning error is reduced (this error occurs when the source of current is placed directly on the Rogowski coil connector). Other electrical performance is equal to Magnelab’s standard RCT-1800-XXX Series. If you are interested in one of these units without the integrator please look at the RCT-600T-000. RCT-600T | Frequent Applications •Energy sub-meters •Power meters •Power quality monitoring •Condition monitoring •Distributed measurement systems Regarding safety: The RCT-600T Rogowski coil meets UL STD 61010-1 and CAN/CSA C22.2 No. 61010. The RCT-600T is designed and made in the USA. The RCT-600T series Rogowski coil can be ordered WITHOUT the integrator when being used with Measurlogic and eGauge power meters. Note: The integrator requires a power supply of 12 to 30V AC or DC, which is not included. Additional information Input AC Product Type Rogowski Coil, Rope CT's Amp Rating 0-5000
