Rogowski coil current sensor RCS-1200 seriesACthree-phase
Add to favorites
Compare this product
Characteristics
- Technology
- Rogowski coil
- Electrical characteristics
- AC, three-phase
- Primary current
Max.: 5,000 A
Min.: 250 A
Description
RCS-1200 Three-Phase RopeCT AC Current Sensor
The RCS-1200 Three-Phase RopeCT AC Current Sensor Series integrator (signal conditioner) converts the RopeCT (Rogowski Coil) input voltage to 0.333 Volts AC output.
The integrator requires a DC power supply which operates from 9 to 36 Vdc. The integrator is available with screw terminals (pictured) or with flexible strain relief cables attached to the integrator. The RCS-1200 comes with three 12″ ropes and has multiple amp rating options.
Note: The integrator requires a power supply of 9 to 36 Vdc, which is not included.
Additional information
Weight 0.55565065325 kg
Amp Rating 1000, 1500, 2000, 250, 2500, 3000, 400, 500, 800
Input AC
Output 0.333 Volt
Product Type Rogowski Coil, Rope CT's
