Drain valve ECR-3
electricfor gasIP67

Drain valve - ECR-3 - MARECHAL ELECTRIC - electric / for gas / IP67

Add to favorites

Compare this product

Characteristics

Operation

electric

Function

drain

Media

for gas

Body

IP67, IP66

Applications

for explosive areas

Temperature

Min.: -50 °C
(-58 °F)

Max.: 105 °C
(221 °F)

Description

TECHNOR® drainage valve for installation on enclosures with increased safety intended for use in explosive atmospheres zones 1 & 2 (gas), 21 & 22 (dust). This valve allows condensation to be drained from inside the enclosure. ECR-3 Zone 1-21, 2-22 ECR-3 Zone 1-21, 2-22 Highlights •Ex II 2 G D Ex e IIC Gb, Ex tb IIIC Db •IP66/IP67 en position fermée IP44 en position ouverte •Operating temperature range: -50°C / +105°C
