Centrifugal pump YPSP Serieswaterelectricindustrial
Add to favorites
Compare this product
Characteristics
- Technology
- centrifugal
- Fluid
- water
- Operation
- electric
- Domain
- industrial
- Applications
- firefighting
- Material
- stainless steel
- Other characteristics
- radial, double
- Flow
Max.: 2,500 m³/h
(88,286.6668 ft³/h)Min.: 50 m³/h
(1,765.73334 ft³/h)- Pressure
Max.: 20 bar
(290.075 psi)Min.: 16 bar
(232.06 psi)- Head
Max.: 180 m
(590'06" )Min.: 20 m
(65'07" )
Description
DESIGN
Single stage, horizontal, separable body, radial impeller,
double suction pumps.
• The back-to-back design of the double entry radial impellers
eliminates all thrust.
• The suction and discharge flanges are along the same axis.
• Easy assembly feature.
• Double suction pumps have the advantage of low NPSH
features.
• The pump and electric motors are connected to the chassis by
means of flexible. Diesel motors can alsa be used.
• in standard manufacture, the impeller, the body abrasion
gasket and the gland are bronze while the casing is of stainless
steel
