- 3-axis machining center
- Masteel America Corp.
3-axis CNC machining center V-12iPvertical24 toolshigh-performance
Add to favorites
Compare this product
Characteristics
- Number of axes
- 3-axis
- Spindle orientation
- vertical
- Number of tool stations
- 24 tools
- Other characteristics
- high-performance
- X travel
300 mm
(11.81 in)- Y travel
410 mm
(16.14 in)- Z travel
510 mm
(20.08 in)- Rotational speed
10,000 rpm, 12,000 rpm, 15,000 rpm
(62,832 rad.min-1, 75,398 rad.min-1, 94,248 rad.min-1)- Power
11 kW
(14.96 hp)- Work feed X-axis
48,000 mm/min
(31 in/s)- Work feed Y-axis
800 mm/s
(31 in/s)Max.: 800 mm/s
(31 in/s)Min.: 0 mm/s
- Table load capacity
500 kg
(1,102 lb)- Weight
5,000 kg
(11,023.11 lb)- Overall length
1,500 mm
(59.1 in)- Overall width
2,600 mm
(102.4 in)- Overall height
2,680 mm
(105.5 in)
Description
A.T.C - - ARM
Table size (L x W) - mm(in) - 600x400 (23.6x15.7)
X/Y/Z axis motor - kW (hp) - 1.6/3/3 (2.1/4/4)
Catalogs
No catalogs are available for this product.
See all of Masteel America Corp.‘s catalogs
