AC servo-drive EW-07528-xx series

controlintegratedwith speed control

Easy-to-use drives offer precise speed control and digital display of rpm—NEMA 4X housings stand up to process and washdown applications Flow rate 0.06 to 3400 mL/min (depends on drive rpm and tubing size) Four digit LED display shows motor rpm—confirm speed setting at a glance Integrated open-head sensor stops drive motor when pump head is opened Reversible motor—purge tubing before or after pumping; pump fluid in either direction LED indicators confirm motor direction Powerful motors let you stack 2 or 4 pump heads for increased flow rates and for multichannel applications Separate speed and power (on/off) control—maintain speed setting while turning pump on/off NEMA 4X (IP66) rated housing Remote control capabilities via a watertight connector on back of drive – Speed control input: 4 to 20 mA or 0 to 10 VDC – Pump direction (CW/CCW) via open collector or contact closure – Start/stop via open collector or contact closure Membrane keypad for easy up-front control of speed, direction, and start/stop Amps Power 2.2 at 115 VAC; 1.1 at 230 VAC These accurate console drives have powerful motors, speed display, and ±0.25% speed control for precise flow regulation—ideal for metering applications. Remote speed control requires cable assembly 77300-32. Operation of the integrated open-head sensor requires use of sensor-equipped L/S Easy-Load II pump heads 77200-30 or 77200-32.
