Vibration test stand FDT

temperaturecomputer-controlledbrake

Brake pads are of central importance in the development and production of brake systems. The dynamic properties of the brake pads are essential characteristics for simulating the brakes during the development process or for quality control in production. The measurement of the dynamic properties (including modal values) of brake pads is described in SAEJ2598. MAUL-THEET offers a complete system that automatically carries out, evaluates and documents these measurements in accordance with SAEJ2598. With the MAUL-THEET test bench it is also possible to determine the dynamic properties (natural frequencies and damping) of other technical components. Advantages & Innovation Vibration measurement with Laser Doppler Vibrometer, accelerometer or microphone excitation by automatic modal hammer Easy to use software Cost and time savings due to low personnel costs Automated test system for determining natural frequencies and damping Calculation of Damping or Loss Factor according to SAE J2598 Quality Sentencing based on Frequency Tolerances Frequency range up to 100 kHz Frequency resolution < 1Hz at 20 kHz damping estimation according to SAE J2598 Project-oriented database structure Central SQL database for multiple workstations One-Click-Reporting Selectable dB Values for Damping Estimation for each Natural Frequency Temperature Measurement with optional Frequency Correction Applications & Integrations damping values for brake pads according to SAE J2598 Quality control Sampling inspection Material testing Product testing Research and Development model updating experimental modal analysis
