Ball valve (-B)-H2-5MN
pneumatically-operatedfor controlmetallic

Ball valve - (-B)-H2-5MN  - Maximator GmbH - pneumatically-operated / for control / metallic
Ball valve - (-B)-H2-5MN  - Maximator GmbH - pneumatically-operated / for control / metallic
Add to favorites
Compare this product


Characteristics

Type
ball
Operation
pneumatically-operated
Function
for control
Body
metallic
Other characteristics
ANSI, for hydrogen
DN

155 mm
(6.102 in)

Pressure

Min.: 2 bar
(29 psi)

Max.: 10 bar
(145 psi)

Temperature

Min.: -73 °C
(-99 °F)

Max.: 80 °C
(176 °F)

Description

Maximator offers various compressed air operated valves (1/4" to 1") as well as check valves for hydrogen refueling systems and generally for use in hydrogen applications. Hydrogen Valves All Valves for Hydrogen refuelling applications are optimized for long service life. Suitable for operation in the temperature range -40°C up to +85°C according to ISO 19880-3 and ANSI / SAE HGV 4.7. Three different drive sizes available: 3" (75 mm), 5" (130 mm) and 8" (200 mm). Special cleaning for use in hydrogen systems to avoid contamination. Leakage test on seat and packing with helium at maximum operating pressure. Specific ​selection of metallic materials to avoid hydrogen embrittlement. Selection of special dynamic sealing elements for low leakage and long service life.
