Rotating table shot blasting machine MDT2 series

for metalsheet metalautomatic

Rotary Table Shot Blasting Machine Rotary table shot blasting machine loads workpiece by turntable. According to the diameter of turntable, it can be divided into 1 200 mm, 1 600 mm, 1 800 mm, 2 2500 mm and so on. The shot blasting machine can be equipped with single or multiple shot blasters according to workpiece products, etc. Its working principle is: the workpiece is placed on the turntable (there is a distance between the workpieces, no contact, no collision), the turntable takes the workpiece into cleaning area for shot blasting cleaning, when transferred to the position of the placement, the workpiece can be removed. Therefore, this type of machine is most suitable for the workpiece one side without cleaning, otherwise the workpiece should be turned over and cleaned again. Brief Profile Mayflay manufactures single-turntable and double-turntable version rotary table shot blasting machine, which both work with the main turntable. Hangers can be equipped on both single-turntable and double-turntables version to have easier and more thorough shot blasting work for hanging work pieces. Multiple working stations can be designed on the main turntable to allow work pieces loading at the same time when other work pieces are in the blasting process to save time of working. This machine is an ideal solution for symmetric parts and the turntable can be programmed to stay at specific position to work with specific blast wheel to have thorough surface cleaning of dissymmetric parts. Turntable loading weight can be customized in accordance with work piece dealt with.
