CNC turning center QTE-100 SG2-axis12 toolshigh-performance
Add to favorites
Compare this product
Characteristics
- Control type
- CNC
- Number of axes
- 2-axis
- Number of tool stations
- 12 tools
- Performance
- high-performance, high-speed, high-rigidity
- Other characteristics
- compact
- Diameter
580 mm
(22.83 in)- Spindle speed
5,000 rpm
(31,415.927 rad.min-1)- Maximum cutting diameter
290 mm
(11 in)- Bar capacity
45 mm
(2 in)- Axe X
195 mm
(8 in)- Axe Z
325 mm
(13 in)- Rapids on X
30 m/min
- Rapids on Z
30 m/min
- Nominal power
7.5 kW, 11 kW
(10.2 hp, 15 hp)- Maximum torque
96 Nm
(71 ft.lb)
Description
MAZATROL conversational programming
Touch screen - Operates similar to your smartphone / tablet
New functions for high-speed, high-accuracy
High-torque spindle
The spindle is designed to provide high-torque machining in the low-speed range. In addition to its high rigidity, the high acceleration and deceleration increases productivity.
Turrets
The bolt-on tool holders are rigidly mounted on the turret by 4 bolts. Thanks to a servo driven motor, drum turret features high-speed, non-lift turret indexing with minimum interference. Tool shank ☐25mm ensures high rigidity machining.
VIDEO
