Digital I O module USB-SSR Series

USBvoltagerugged

The USB-SSR Series interface devices provide support for solid state relay (SSR) modules. Each device is designed with a heavy-duty chassis for rugged DAQ applications. Measurement Computing DIO high voltage and relay USB product offerings includethe USB-PDISO8 Series, USB-ERB Series, and USB-SSR Series.The USB-PDISO8 Series offers eight isolated AC or DC inputs and eight electromechanical relays in a single digital I/O system. The USB-ERB Series enables a PCor laptop to control eight to 24 electromechanical relays.The USB-SSR Series can monitor and control eight to 24 standard size solid staterelay (SSR) I/O modules (relays sold separately).All devices in these series come in a heavy-duty metal enclosure with integratedmounting slots, which ensures that the devices are rugged enough for any DAQapplication. • USB-PDISO8 Series − 8 Form C relays − 8 isolated AC or DC inputs • USB-ERB Series − 8 or 24 Form C singlepole double-throw (SPDT)electromechanical relays. • USB-SSR Series − 8 or 24 input or outputchannels to control andmonitor solid state relays. • Screw terminal or headerconnectors • Heavy-duty chassis withintegrated mounting slots • Includes external power supply(required for all devices) SSR Digital I/O ControlModulesUSB-SSR Series OnlyThe USB-SSR08 provides mounting locations for eight SSR digital I/O modules,and the USB-SSR24 provides mountinglocations for 24 SSR modules.SSR digital I/O modules are relay control modules that provide 4000 Vrms ofoptical isolation.
