5/6-axis CNC milling machine NORMAPROFIL T series
verticalbridgewith fixed table

5/6-axis CNC milling machine - NORMAPROFIL T series - MECANUMERIC - vertical / bridge / with fixed table
5/6-axis CNC milling machine - NORMAPROFIL T series - MECANUMERIC - vertical / bridge / with fixed table
5/6-axis CNC milling machine - NORMAPROFIL T series - MECANUMERIC - vertical / bridge / with fixed table - image - 2
5/6-axis CNC milling machine - NORMAPROFIL T series - MECANUMERIC - vertical / bridge / with fixed table - image - 3
5/6-axis CNC milling machine - NORMAPROFIL T series - MECANUMERIC - vertical / bridge / with fixed table - image - 4
Add to favorites
Compare this product

Go to the MECANUMERIC website for more information

Characteristics

Number of axes
5/6-axis
Spindle orientation
vertical
Structure
bridge, with fixed table
Machined material
for aluminum, for composites, for wood
Associated functions
cutting
Applications
for aeronautics, for large workpieces, for panels, for model making, foam, for the mold industry, for the plastics industry, for the aeronautical industry, for molds
Other characteristics
high-speed, precision
X travel

3,100 mm
(122.05 in)

Y travel

2,100 mm
(82.68 in)

Z travel

870 mm
(34.25 in)

Rotational speed

24,000 rpm
(150,796 rad.min-1)

Power

15 kW
(20.39 hp)

Description

Fixed table, mobile gantry, 4 cartesian axes, 2 polar axes The complete and versatile NormaProfil T series 5-axis CNC milling machine is optimized for machining large parts produced by thermoforming. TECHNOLOGIES Transmission by ball screw on the 4 Cartesian axes (X1, X2, Y, Z) 2 rotary axes (C: +/- 200 ° and A: +/- 200 ° depending on the electrospindle) Many electrospindles available The NormaProfil T series is optimized for workpiece machining in the following materials: Plastic and composites Synthetic resins PU and PS foam Wood and wood products Aluminum Brass and alloys SOME OF THE POSSIBLE OPTIONS Front and rear automatic doors Movable partition for commuter work (manual or automatic) Vacuum plate for holding parts or tools (vacuum technology by side channel turbines or by vacuum pump) Static tool magazine (6,10,15 tools) Tool measuring probe Sound-absorbing full cover Other useful formats
