Process indicator MPPV010 P6

voltageloaddigital

OUT OF PRODUCTION - 4½ digit display in a 48x96 box for strain gauge (load cell) input (±3000 points display). Optional 3 relè (only with 220V power supply), output and analogue and serial autput. The MPPV010 P6 model is an instrument with 16 bit A/D converter for strain gauge transducer. The available measuring scales are listed in the "Features" section. The instrument has the following functions: ± 30000 points display reading of any input value inside the requested range batching function reading at 40 conv/sec "filtering" process for instrument readings zeroing of automatic reading function maximum or minimum peak-hold total weight The instruments can be ordered with the following options: normal or optoisolated bidirectional serial output or monodirectional version for printer 3 relay alarm outputs for normal working or window alarms completely programmable for value, hysteresis and delay analogue output (4÷20mA or 0÷20mA or 0÷10V). Readings: ±30000 digits Accuracy better than: 0,3% Thermal stability: 50 ppm/°C Transducer power supply: 5V/ 30mA Analogue outputs features: Outputs: 4÷20mA - 0÷20mA - 0÷10V Max load for current output: 400Ω Min. load for voltage output: 1KΩ Resolution: 12 bit Power supply: 90÷260Vac/Vdc, 25Vac, Vcc o Vpt (12÷30Vdc) Power absorption: 3W Max working temperature: 50 °C Digits height: 13mm Dimensions: 48x96 (75 mm. Depth) Mounting plate: 44.5mm (h) x 92.5 mm (l) Weight: 250 gr. Mounting: by bolts OPTIONS AND SERIAL OUTPUTS SR2: 2 relay alarms SR3: 3 relay alarms (only with 220V power supply)
