Digital clamp meter DCM305E
portable600 mA6 A

Digital clamp meter - DCM305E - MEGGER - portable / 600 mA / 6 A
Digital clamp meter - DCM305E - MEGGER - portable / 600 mA / 6 A
Add to favorites
Compare this product


Characteristics

Display
digital
Form
portable
Max current
100 A, 60 A, 6 A, 600 mA
Safety rating
cat III
Additional features
frequency
Power supply
AAA LR03 batteries
Other characteristics
AC, TRMS
Max AC current

Max.: 100,000 mA

Min.: 6 mA

Max AC current resolution

Max.: 100 mA

Min.: 0 mA

AC current precision

1 %, 2 %, 10 %

Process temperature

Max.: 50 °C
(122 °F)

Min.: 0 °C
(32 °F)

Length

203 mm
(7.99 in)

Width

78 mm
(3.07 in)

Height

42 mm
(1.65 in)

Weight

300 g
(10.58 oz)

Description

• 0.001 mA resolution • Up to 100 A range for standard AC current measurements • TRMS reading • Low pass filter to aid stability of readings • Auto, data and peak hold • 40 mm jaw • Analogue bargraph display for trending The DCM305E is perfect for identifying and measuring the earth leakage current in a circuit where the RCD keeps tripping out unexpectedly. The measured result will quickly identify whether the earth leakage current present is excessive, causing the RCD to trip, or if the RCD itself is over sensitive or faulty. Specially designed to check earth leakage currents, the DCM305E is an efficient and highly versatile instrument. It has six ranges 6 mA, 60 mA, 600 mA, 6 A, 60 A, 100 A with a minimum resolution of 0.001 mA on the 6 mA range. Its upper range also enables TRMS AC current measurements up to 100 A. The 40 mm jaw has been designed to allow measurements on both insulated and non-insulated conductors and this clamp meter vastly improves measurements on circuits with harmonics/electric noise on the cables using a low pass filter of 50/60 Hz. Safety is of the utmost importance and with that in mind, the DCM305E exceeds the latest safety design standards IEC1010-2-32 and EMC requirements and also includes a tactile hand barrier/hand guard in the instrument case design to help protect you when working.
