Direct current motor MEBGVF series

synchronousIP23large

Menzel observes premium quality standards to manufacture MEBGVF 100 to MEBGVF 315 series DC motors in compliance with current EN60034 and IEC 34 requirements. Armature voltage range: Up to 1,000 V DC Torque: Up to 200 kNm Shaft height: Up to 900 mm Mounting: IM B3 for horizontal installation IM V1 for vertical installation IM B35 for flange and food adaptors Standard types of cooling systems: IC 06, IC 17, IC 37, IC 86 W, IC 666 Standard degrees of protection: IP 55 [IC 37 / IC 86 W / IC 666] IP 23 [IC 06 / IC 17] Custom adaptations and special designs can be implemented on request. Typical applications: • Extruder • Foil machines • Paper and packaging machines • Machine tools • Wire drawing machines • Presses, kneaders and mixers • Cranes and conveyors • Rolling mill applications • Test bench applications etc. Our choice of excellent materials, strict quality control, and continuous design refinements that reflect the evolving state of the art ensure you can rely on the top quality and durability of our systems.
