Hot air hose 913072
galvanised steelfiberglassfor fume extraction

Hot air hose - 913072 - MERLETT - galvanised steel / fiberglass / for fume extraction
Hot air hose - 913072 - MERLETT - galvanised steel / fiberglass / for fume extraction
Hot air hose - 913072 - MERLETT - galvanised steel / fiberglass / for fume extraction - image - 2
Hot air hose - 913072 - MERLETT - galvanised steel / fiberglass / for fume extraction - image - 3
Hot air hose - 913072 - MERLETT - galvanised steel / fiberglass / for fume extraction - image - 4
Hot air hose - 913072 - MERLETT - galvanised steel / fiberglass / for fume extraction - image - 5
Add to favorites
Compare this product

Characteristics

Use
for hot air
Material
galvanised steel, fiberglass
Applications
for fume extraction
Other characteristics
flexible, abrasion-resistant, chemical-resistant, with smooth inner surface, crush-resistant, coated, spiral
Inner diameter

Max.: 305 mm
(12.008 in)

Min.: 51 mm
(2.008 in)

Outer diameter

Max.: 310 mm
(12.205 in)

Min.: 55 mm
(2.165 in)

Pressure

Max.: 1.2 bar
(17.405 psi)

Min.: 0.1 bar
(1.45 psi)

Temperature

Max.: 150 °C
(302 °F)

Min.: -50 °C
(-58 °F)

Delivered length

4 m
(13'01" )

Description

Hose made of neoprene coated fibreglass with galvanised steel spiral, for suction of fumes and hot air. MOOTH SURFACE
