Insulation tester MI 3288

insulation resistanceinsulation resistance and continuityearth resistance

MI 3288 Earth Insulation Tester is a portable, battery powered test instrument with excellent IP protection and designed for high altitude (300 V CAT III at 4000 m). MEASURING FUNCTIONS • Earth resistance 4 - pole • Selective earth resistance with 1 clamp • Specific earth resistance Ro Wenner and Schlumberger method • Earth resistance with 2 iron clamps • Earth potential • Step and touch voltage measurement with external P/S probe • Insulation resistance with DC voltage from 50 V to 2500 V and PI, DAR calculation • Varistor test 2,5 kV • Current measurements with clamps AC • TRMS voltage and frequency measurements • Low Ohm measurements with 7 mA and 200 mA DC test current KEY FEATURES • Possibility of performing all main types of earth measurements with a single instrument • Multi-frequency test signal for best noise immunity • Insulation range: wide range of insulation test voltages from 50 V to 2500 V, resistance measuring range up to 100 GΩ • Overvoltage category 600 V CAT II, 300 V CAT III; at 4000 m above sea level • 4.3’’ colour LCD display with touch screen • Programmable AUTO SEQUENCEs • High degree of protection • 4-wire 200 mA DC resistance measurement • Support for single or automated measurements • Built-in charger and rechargeable Li-ion batteries as standard accessory • BT communication with PC, Android tablets and smart phones via built-in BT • PC SW Metrel ES Manager for measurement pre and post processing: preparation of the test structure, result download, tree-view, table view and graphical view, storing and printing
