Pneumatic stapling machine SGR 1 / QE

foot-operatedtable-topwith 1 head

Pneumatic stapling device with side arm and 1 stapling head A 20, B 36 or C 13 for coiled staples. For stapling carton blanks, carton trays, telescopic type of cartons. Stapling device with side arm and with 1 stapling head for coiled staples for the stapling of cardboard blanks to telescope cartons, carton trays, insert covers, as well as plastic, rubber and thin metal parts. Without reloading 4000 or 5000 staples can be stapled. Staple process is triggered via foot valve. Stapling device SGR 1/QE/C 13-30/25 (Ill.) • SGR 1 / QE = transverse stapling. • Working height adjustable 960 - 1500 mm. • Max. throat depth: 439 mm. • Inclusive foot valve and maintenance unit. The staple device an be equipped with various stapling heads for coiled staples. See stapling heads A 20, B 36, C 13 and E 24. Pneumatic stapling device with an optional transverse or longitudinal stapling (QE and LE) can be delivered. See also SGR 2 Double Head Device.
