Pressure blast cabinet SMG 160 Kompakt S/D

hand

ADVANTAGES OF THIS BLASTING SYSTEM: Combines the high-quality equipment of the SMG 160 with low spatial requirement With components accessible from the side, this system can be installed directly against a wall With modularly designed workshops, the system can be integrated into machining cells WORKING SPACE 1350 x 1100 x 1100 mm (W x D x H) BLASTROOM Dustproof vacuum cabin in stable sheet steel construction WORKING GLOVES Special rubber, wear-resistant, inside cotton, firmly attached to the cabin against dust DOORS Two side doors, dust-tight closing, double-walled, sound-absorbing foamed, lockable, with electrical switch-off protection BLASTING MATERIAL RECOVERY Via coordinated MHG recovery system SERVICE ON / OFF switch for suction and lighting, pressure regulator, manometer and foot switch VISORS Safety glass, 500 x 320 mm, interchangeable without special tool BEAM LIGHTING Wear-free mounted outside, very good illumination by halogen, optional LED lighting unit MHG BLASTING GUNS High-performance blast gun system MHG, with optimum efficiency, operation via foot pedal, available with nozzles in different sizes and materials WORKPIECE BLOW-OFF NOZZLE For cleaning the blasted workpieces and the blasting chamber MHG PRESSURE JET SYSTEM (OPTIONAL) Available with different boiler sizes, including built-up abrasive recovery system
