Self-centering lens holder A-LINE™

self-centering lens holder
self-centering lens holder
self-centering lens holder
self-centering lens holder
self-centering lens holder
self-centering lens holder
self-centering lens holder
self-centering lens holder
Add to favorites
Compare this product


Characteristics

Other characteristics
self-centering

Description

A-Line™ Series alignment mounts are designed to make mounting, aligning and focusing optics fast and easy. The lens mounts in the A-Line™ family provide convenient and affordable solution for mounting various size and thickness lenses. •Fixed lens mounts for 6.4 to 76.2 mm diameter lenses •Self-aligning design compatible with A-Line guide rod •Thin edge with large clear aperture •10 pack option available Mounting, Aligning and Focusing Lenses Fast and Easy A-Line™ series of self-aligning mounts are designed to make mounting, aligning and focusing lens groups fast and easy. How? The front of each lens mount has a special 6 mm alignment hole, which can be used with LH-GR Series Guide Rods such that several A-Line lens holders can be mounted together in a self-aligned row. This overview video demonstrates the easy and fast aligning process using the A-Line lens mounts. Space Saving Design Several A-Line self aligning optic mounts can be grouped on the same guide rod to save space. Shown are the LH-1DB with UPA-CFC fiber adapter, the LH-RMS with microscope objective and the LH-1A with lens. Increased Stiffness for Reduced Vibration A-Line™ lens holders are constrained both by the post/post holder as well as by the A-Line guide rod creating a "strong-box" structure that is significantly stiffer and less susceptible to vibration than individually post-mounted lenses. Shown on the right is A-line lens mounts and rods used together with TSP Series Miniature Optical Mounting Post and MSPH Series Miniature Slotted-Base Optical Post Holders.
