Audio amplifying integrated circuit MCP601

powercurrentvoltage

MCP601 operational amplifier (op amp) has a gain bandwidth product of 2.8 MHz with low typical operating current of 230 uA and an offset voltage that is less than 2 mV. The MCP601 uses Microchip's advanced CMOS technology, which provides low bias current, high-speed operation, high open-loop gain, and rail-to-rail output swing. The MCP601 operates with a single supply voltage that can be as low as 2.7V, while drawing less than 325 uA of quiescent current. The MCP601 is available in standard 8-lead PDIP, SOIC, TSSOP and 5-lead SOT-23A packages. This amplifier is ideal for industrial process control, low-power battery-operated devices, portable equipment, data acquisition equipment, test equipment and low-end audio applications. Product Features Low Input Bias Current:1 pA (typ.) Low Input Offset Voltage: 2 mV (max.) Unity Gain Stable Rail to Rail Output Extended Temperature Range Parametrics CMRR Min (dB) - 75 Enhanced EMI Protection - No Input Voltage Noise Density (nV/rt(Hz)) - 29 PM (deg) - 50 PSRR Min (dB) - 80 # Per Package - 1 Slew Rate (V/µs) - 2.3 Vos Max µV (microvolt) - 2000
