Thermal circuit breaker IR6000SV serieshigh-speedhorizontalvertical
Add to favorites
Compare this product
Characteristics
- Type
- thermal
- Electrical characteristics
- high-speed
- Operating mode
- horizontal, vertical
- Applications
- for railway applications, for DC applications
- Primary current
2,500 A, 4,000 A
- VDC
1,800 V, 3,600 V
Description
The IR6000SV Line is the right choice where a very powerful solution is required on on-board application for EMU, High speed Train and locomotive rolling stock.
The IR6000SV represents the most experienced extra heavy-duty line. To be considered for applications requiring high thermal current and high breaking current for systems up to 4 kV.
The IR6000SV Line is a range of single pole, air, high speed circuit breakers for DC applications with air breaking, available in two voltage ratings of 1800 and 3600 Vdc and thermal currents up to 4 kA.
IR6000SV Series includes:
IR6040SV, Vertical mounting, mostly used for locomotive
IR6021SV, Horizontal mounting, only available within its own box for roof mounting
IR6025SV, Horizontal mounting, only available within its own box for underframe mounting
