DC gear-motor ACCEpermanent magnetplanetarygear train
Add to favorites
Compare this product
Characteristics
- Motor type
- DC, permanent magnet
- Type
- planetary, gear train
- Shaft orientation
- coaxial
- Power
- 10 W...50 W, 50 W...100 W
- Voltage
- 24 V, 12 V
- Torque
- 20 - 50 Nm
- Other characteristics
- aluminum frame, IP65
- Gear ratio
Max.: 2,209.5 unit
Min.: 37 unit
Description
MOTOR: direct current with permanent magnets, totally enclosed with external ventilation. Class F winding. 24 Vdc power supply. Absorbed power 60 W. IP65 protection according to CEI EN 60529.
GEAR UNIT: fi rst stage with die-cast aluminium case, second stage in steel. Case-hardened and hardened gear pairs with shafts rotating on roller bearings. Lubrication with long life oil. Sealing rings made in special rubber for high temperatures. 15 gear ratios (i) available, from 37 to 2209.5. Rated torque 23.5 Nm. Version B3 or B5.
