Die sinking electrical discharge machine SG-S series

CNCprecision

The rock-solid machine base of the SG-Series is your assurance of precision and ­durability. The choice of high-class components ensures the long-term reliability of the machine system. The simplicity of the control and the programming itself – a hallmark of EDM machines by Mitsubishi Electric – allows the operator to focus on the essential, i.e. the proper planning of the various eroding tasks. And here, too, this is aided by the intelligent control strategy with integrated job planning and an efficient evaluation of a wide range of operating data, including actual job costing. The standard equipment of the SG-S rounds off the picture. A fire extinguishing system and C-axis with zero-point clamping system are part of the machine’s standard equipment. Additional useful features enable you to tailor the configuration to your individual requirements. Acceleration of up to 1.6 G and travel speeds of up to 20 m/min enabled by the modern drive unit of the Z axis. The in-house AI technology uses the advantages of these values perfectly. Inclusive of safety: collision protection in all axes. Rock-solid machine build, exactly as it should be. Sophisticated, cleaned up and absolutely durable. These principles are well proven for decades and will be casted into each and every new machine. The use of high-class components inclusive. Good accessibility thanks to the three-sided lifting tank allows convenient and quick set-up.
