Bladder accumulator DA-130S-40

plasticstorage

Driven dancer accumulator with servo motor for constant tension control. The wire run is from right to left, optionally also from left to right possible. A laser sensor is used to measure the distance/length in the memory. Servo motor ca. 1,5 kW Storage path 40 Meter Wire/cable diameter 0,5 - 2,0 mm Tension force 4 - 100 N max. speed 500 m/min Overall height ca. 3,5 m Roller plastic-ceramic Ø 130 mm
