Addressable manual call point CP150 series

explosion-proofATEXfire alarm

The CP150 manual call point range has been approved for use in potentially explosive atmospheres and harsh environmental conditions. Typical applications are Oil and Gas, On-shore and Offshore, Chemical, Petrochemical, Refineries & Marine locations etc. It is compatible for use with a PLC, DCS and ESD systems via 4-20mA output. It is ideally suited for use in fire alarm systems and an addressable option with diode fitted is available. The range also offers an additional visual LED indication option; red, green (or both) can be fitted. When fault or alarm status arises the green LED will be overridden by the red LED. The design allows for termination inside the unit. Features • Approved by ATEX, IECEx • CQST (Available on request only) • ATEX: II 2G Exd IIC T4 – T6 (Incorporating IIA & IIB) • Zones 1, 2, 21 & 22 • Conforms to EN (IEC) 60079-0, EN (IEC) 60079-1 and EN54 • Dustproof & Weatherproof
