Strobe beacon X195/X197 series

flashxenon24 Vdc

The X195 and X197 are suitable for security, process control & general industrial signalling applications. These beacons are of the Flashing mode type (single stage alarm) Xenon beacons (sometimes called strobes) are controlled via a PCB and put out a very brief but bright flash of white light by ionizing and then discharging a large current through the xenon gas. The design allows for termination inside the enclosure. The X195 deep base version offers 2 x M20 side knockouts and 1 x M20 rear. The shallow base (low profile version) allows for cable entry of up to 5mm on the side of the unit (x2) and 1 x M20 knockout at the rear. The X197 high power version only allows for internal connection via the M20 rear knockout. Due to the power rating the unit has a rated ’On’ time of 2 hours in any six. Features • Continuously rated – Not X197 • Suitable for conduit box or wall mounting • 200 prime light output above the vertical axis • WH = White back box • B = Shallow base • Dustproof and Weatherproof Material UV Stable ABS Plastic Base
