Partition insertion machine 2001

automaticfor cardboard boxes

Machine suitable to pick-up, open and insert automatically solid carton divisions into cases. Features • Divisions’ magazine adjustable to different sizes and with a pitch-to-pitch movement according to division thickness. • An electro-pneumatically controlled system compensates for the thickness difference between division center and ends. • A carriage with suckers picks up, opens and inserts divisions into cases (this system enables to maintain the division blocked and squared up to its insertion inside the case). • An automatic centering basket enables an easy insertion of the division inside the case (only for a division insertion into an empty case). • “Touch-screen” display to manage machine functions, the changeover and to visualize possible anomalies. • Machine complete of electrical installation, electrical panel and safety guards. • Machine managed by a PLC Siemens S7. N.B. This machine can be equipped of a motorized, vibrating conveyor and of a pushing unit electropneumatically controlled to make easier divisions lowering between bottles inside case.
