Crawler wood chipper 1300B

The Morbark 1300B Tub Grinder combines heavy-duty construction with the latest technology, including the Morbark Integrated Control System, which allows you to monitor critical machine parameters. With a full breakaway torque limiter system, hydraulic augers and a laser-cut hammer mill, the 1300B tub grinder is the most popular grinder on the market. Replaceable, one-piece anvil and tub floor wear plates make maintenance easy and reduce downtime. The optional track undercarriage makes it easy to bring the grinder right to the material. MORBARK INTEGRATED CONTROL SYSTEMS (MICS) Automatically adjusts feed rates and monitors pressures and feed wheel position to maximize production and engine efficiency. LENGTH (TRANSPORT) - 45′, 13.72 m LENGTH (OPERATING) - 60’10”, 18.54 m HEIGHT (TRANSPORT) - 13’6″, 4.11 m WIDTH - 11’11”, 3.63 m GROSS WEIGHT NCL - 74,580 lb, 33,830 kg AXLE WEIGHT NCL - 50,520 lb, 22,915 kg TONGUE WEIGHT NCL - 24,060 lb, 10,915 kg GROSS WEIGHT WCL (OPTIONAL) - 86,520 lb, 39,245 kg AXLE WEIGHT WCL (OPTIONAL) - 56,000 lb, 25,400 kg TONGUE WEIGHT WCL (OPTIONAL) - 30,520 lb, 13,845 kg ENGINE - CAT FUEL CAPACITY (TANK) - 505 gallons, 1,912 litres HYDRAULIC OIL CAPACITY - 205 gallons, 776 litres SCREEN AREA - 3,730 sq in, 24,064 sq cm TRACKED UNIT LENGTH (TRANSPORT) - 40’9″, 12.42 m TRACKED UNIT LENGTH (OPERATING) - 48’8″, 14.83 m TRACKED UNIT HEIGHT (TRANSPORT) - 12′, 3.66 m TRACKED UNIT WIDTH - 11’11”, 3.63 m TRACKED UNIT GROSS WEIGHT - 94,320 lb, 42,785 kg TRACKED UNIT ENGINE - CAT TRACKED UNIT FUEL CAPACITY (TANK) - (2) 300 gallons, 1,135 litres TRACKED UNIT HYDRAULIC OIL CAPACITY - 240 gallons, 908 litres TRACKED UNIT SCREEN AREA - 3,730 sq in, 24,064 sq cm
